LigoPTP 6-N/ 6-25 RapidFire Point-to-Point Bridge
The LigoPTP RapidFire is a high-performance wireless bridge for long-distance heavy-duty point-to-point applications. It delivers an outstanding 700Mbps with its powerful hardware platform that supports modulations of up to 256-QAM and 30dBm output power, making it the top performer even in dense and noisy environments. The W-Jet proprietary protocol, engineered for capacity-demanding PTP scenarios, minimizes interference and stabilizes latency even with long-distance links.
86+17722547662
Contact us
- Huancang Road, Luohu District, Shenzhen City, Guangdong Province
- 86+17722547662
- fanchao
- 17722547662@163.com
The 6GHz Generation
The LigoPTP RapidFire is a high-performance wireless bridge for long-distance heavy-duty point-to-point applications. It delivers an outstanding 700Mbps with its powerful hardware platform that supports modulations of up to 256-QAM and 30dBm output power, making it the top performer even in dense and noisy environments. The W-Jet proprietary protocol, engineered for capacity-demanding PTP scenarios, minimizes interference and stabilizes latency even with long-distance links.
Outstanding Capacity
RapidFire delivers an extremely high 700Mbps throughput via its unique and powerful RF design that supports up to 256-QAM modulation and 30dBm output power. Our proprietary W-Jet V protocol, specifically engineered for high performing PTP scenarios, minimizes interferences even across long distances and stabilizes latency within 2-4 ms.
Ultra High Performance
Wireless Bridge
700Mbps
A 6GHz point-to-point system with exceptional performance that delivers 700+ Mbps throughput. The carrier grade design with a simple and friendly user interface makes RapidFire an ideal device for high capacity and performance demanding links.
Professional Design
In addition to achieving maximum performance, LigoWave focuses on delivering flexibility and ease-of-use in our RapidFire series. The robust mounting bracket enables rapid deployment of the links and ensures survivability during high wind-load. The integrated antenna possesses a 45° rotation option which increases installation flexibility; especially advantageous in noisy spectrum areas. A GORE© membrane vent allows fast pressure equalization of the IP-67 rated cast aluminum enclosure to prevent condensation and to ensure seal performance . A detachable handle eases transporting the devices up towers and over rough terrains. Newly designed RGB LEDs indicate different device statuses and signal levels (in 1dBm steps) when aligning the antenna.
45°
Antenna Tilt Option
RapidFire can be rotated 45° to increase installation flexibility, which is extremely useful in noisy environments.
Powerful All-in-One Hardware Platform
LigoWave RapidFire delivers powerful performance with its new 1.2GHz CPU dedicated for data processing and high (200,000) packet per second delivery. Equipped with two Gigabit Ethernet ports, one with PoE passthrough, the unit allows for 1+1 (failover) or repeater links and is ideal for high-security video surveillance scenarios. RapidFire incorporates integrated surge and ESD protection according to IEC standards and passes Class 4 requirements.
Wireless Configuration Interface
An internal 2.4GHz radio allows access into the Rapidfire GUI by wireless connection with any WIFI equipped device. This feature expedites the installation of links and alleviates the problem of troubleshooting in difficult-to-reach locations. Tests prove accessibility even when mounted on top of a 10-story building while standing 20 meters (65ft) away!
Infinity Controller
The Infinity Controller is a wireless network management platform currently available for the NFT series and which will soon be coming to the LigoDLB and LigoPTP series. The controller allows users to install, manage, and expand NFT Wi-Fi networks using automated device onboarding, predefined network scenarios, and other features. The Infinity Controller for the DLB and PTP series will enable users to simplify the way they build, expand, and maintain their wireless networks.
Powerful OS
The LigoPTP operating system ensures easy and rapid deployment of point-to-point links with stable, fast performance. An intuitive and responsive user interface adjusts the layout based on the size of your screen. Essential tools including Setup Wizard, link test, antenna alignment, spectrum analyzer, and site survey are included to make set-up and troubleshooting more efficient. Automatic mechanisms such as auto-channel and automatic transmit power control optimize the link for maximum performance even in areas with high interference.
Setup Wizard
A link setup wizard guides the installer through the important steps of the set-up process.
Single Side Configuration
LigoPTP RapidFire simplifies link configuration by supporting single side configuration as parameters are automatically applied to slave units once set on the master side.
Easy Pre-Configuration
Multiple options to pre-configure LigoPTP RapidFire devices are displayed in a scheme below. Devices can be connected with each other using wired or wireless connectivity. End-user device can also connect to the master device using 2.4GHz access radio or using wire to the Ethernet port of the master device. LigoPTP RapidFire devices can be discovered using bonjour and SSDP protocols as well.
Radio
Wireless Protoco | W-Jet V |
Radio Mode | MIMO 2×2 |
Frequency Range | 5.900–6.400GHz |
Channel Size | 5, 10, 14, 15, 20, 30, 40, 60, 80MHz |
Modulation Schemes | OFDM (256-QAM, 64-QAM, 16-QAM, QPSK, BPSK) |
Data Rates @ 80MHz | 866, 780, 650, 585, 520, 390, 260, 195, 130, 65Mbps |
Duplexing Scheme | TDD |
Error Correction | BCC, LDPC |
Automatic TPC | Supported |
Coming soon
Antenna
LigoPTP 6-N RapidFire | 2 N-type Connectors |
Wired
First Interface | 10/100/1000 Base-T with PoE IN (RJ45) |
Second Interface | 10/100/1000 Base-T with PoE OUT (RJ45) |
Physical
Dimensions without mount
LigoPTP 6-N RapidFire | Length 399mm (15.7‘’), Width 174mm (6.8‘’), Height 47mm (1.8‘’) |
Mount Length Till Pole | 124mm (4.8‘’) |
Weight including mount:
LigoPTP 6-N RapidFire | 2.9kg (6.3lb) |
Power
Power Input Method, Voltage | PoE 802.3at, Isolated 42–57VDC |
Max Power Consumption | 8.6W |
Power Output Method, Voltage | PoE 802.3af, 48VDC, 12.95W Maximum |
PoE Inserter and AC/DC Adapter are Included |
Environmental
Operating Temperature | –40°C (–40°F) ~ +65°C (+149°F) |
Humidity | 0~90% (Non-Condensing) |
Software features
- Wizard for fast link setup
- Centralized control from master: A) Common wireless link parameters; B) Individual slave parameters
- Smart Auto-channel
- Robust data security
- QoS with hardware acceleration
- Spectrum analyzer
- Wireless signal and device state indication on RGB LEDs
- Dual firmware image
Management
Dedicated 2.4GHz Radio for Management
System Monitoring | STP/I SNMP (V3) TOKIO, GUI/HTTP(S), Shell/SSH and WNMS |
System Configuration | GUI/HTTP(S) and WNMS |
Regulatory
Certification | FCC/IC/CE |
Antenna Specifications
Frequency Range | 5.85–6.45GHz |
Gain | 25dBi |
Cross-Pol Isolation | 27dB |
VSWR | <1.4 |
Azimuth Beamwidth (H-pol) | 8° |
Azimuth Beamwidth (V-pol) | 8° |
Elevation Beamwidth | 8° |
